SPECIFICATIONS
| Max sewing speed | 6-10M（Adjusted by different fabric） |
| Max stitch length | 2-5mm |
| Presser foot lift height | 18mm |
| Needle bar stroke | 33.6mm |
| Needle gauge | 3.2/3.2mm（customizable） |
| Bed size in diameter | 110-185mm（Can be changed by changing attachment.） |
| Total motor power | 2.82KW（Can be changed as required.） |
| Motor power | 550W 380V,220V 370W（Electronic positioning motor 220V 650W） |
| Needle type | UY128（19-23） |
| Lubrication | individual oiling by hand |
| Pin number | 3 |
| Conveyor length | 9.2m |
| Device total length | 14-16m |
Main Features
1)High production efficiency, the highest speed can reach 9 meters per minute.
2) Failure rate is low, because the machine adopted the most advanced transmission structure both at home and abroad, the failure rate can be reduced to about 40%.
3) It can save more oil, oil seal is good, there is enough oil during working, therefore it will not lead to the components’ service life to be shorten because of lack of oil.
4)Sewing machine main motor adopts energy-saving servo motor, so the speed of the sewing machine can be adjusted arbitrary among the range of 50-3600r.p.m/min as working required. LED display screen can display the speed of the sewing machine in the work.
Main Functions
1)Feeding function
2)Backing material returning function
3)Breaking stop function
4)Computer adjust needle function
5)Automatic fixed length cutting function
6)Hidden type threading lighting
7)Machine needle cooling function
8)Sharpening function
9)Feeding detection function
10)Multifunctional adjustable hemming device
